| 4G LTE(European or USA)Public Network | ||||
| Type | P-387 | |||
| Working Voltage | DC：7.5V | |||
| Network System | LTE-FDD/WCDMA/GSM | |||
| Frequency Range CAT.4 | European Edition(E3C): 1.LTE FDD:B1,B3,B7,B8,B20,B28 2.LTE TDD:B40 3.WCDMA: 2100(B1)/900M(B8) GSM: 900(B3)/1800MHz(B8) AU Edition(A1C): 1.LTE B1,B2,B3,B5,B7,B8,B28,B40 2.WCDMA B1,B2,B5,B8 3.GSM quad-band US Edition: LTE FDD:B2,B4,B5,B12,B17 WCDMA: 1900/850MHz GSM：850/1900MHz |
|||
| Maximum Transmit Power | – LTE: 23 ±2.7dBm (Power Class 3) – WCDMA : 24 +1/-3dBm (Power Class 3) – GSM900 : 33±2dBm (Power Class 4) – GSM1800: 30±2dBm (Power Class 1) |
|||
| Standard Power Consumption | Standby Current：80-120mA@RX-75dBm for LTE | |||
| Average Operating Current：220mA@RX-75dBm for LTE | ||||
| Max Current：800mA@RX-104dBm | ||||
| Receiving Sensitivity | -106dBm | |||
| Battery | Polymer Lithium Battery | |||
| Charge Mode | TYPE-C/ Seat-charger | |||
| Antenna | External Dual Mode Antenna | |||
| Operating Temperature | -20℃ ~ +50℃ | |||
| Weight | 360g | |||
| Size: Length*Width*Thickness(mm) | 125x60x36（Without Antenna） | |||
| SIM Card | Nano SIM | |||
| GPS(Optional) | ||||
| Frequency | 1575.42MHz | Tracking Sensitivity | -155dBm | |
| Capture Sensitivity | -143dBm | First Positioning Time(Outdoors) | Hot Start:4s | |
| Cold Boot:55s | ||||
| Refresh Rate | 2-4HZ | Antenna | Active Antenna | |
| Power Consumption | 35mA | Check | Native Latitude And Longitude Display And Platform Scheduling Software | |
Main Function
| POC |
| LTE-FDD/WCDMA/GSM. |
| 1.7-inch Color Screen |
| 20 Operation Buttons |
| Lithium Polymer Battery |
| GPS (Optional) |
| Dialing Single Call |
| Multi-group Monitoring |
| Multi-member Single Call |
| SOS |
| Intercom Tone Switch |
| Key lock |
| Battery Display |
| Low Battery Alert |
| Hour reporting |
| Voice Support:4K/8K |
| Dual Card Automatic/Manual Switch |
| Platform System: REALPTT |
| IP66 Waterproof |
