The P-287C is a professional LTE PoC radio designed for security teams, fleet management and industrial users. Equipped with GPS positioning, REALPTT compatibility and K-headset support, it delivers reliable nationwide communication and efficient dispatch management.
| P-287C 4G LTE Technical Specification | |||
| Product Parameters | |||
| General | |||
| Type | P-287C | ||
| Equipment Name | LTE Public Network Digital Walkie Talkies | ||
| Working Voltage | DC:6.5V-8.4V, Typical Value:7.5V | ||
| Network System | LTE-FDD/WCDMA/GSM | ||
| Frequency Range | Europe&Southeast Asia： FDD：B1/B3/B5/B7/B8/B20/B28 TDD：B38/B40/B41America&Australia B2/B3/B4/B5/B7/B8/B28/B66 | ||
| Maximum Transmit Power | – LTE: 23 ±2.7dBm (Power Class 3) / – WCDMA : 24 +1/-3dBm (Power Class 3) / – GSM900 : 33±2dBm (Power Class 4) / – GSM1800: 30±2dBm (Power Class 1) | ||
| Standard Power Consumption | Standby Current:40-120mA@RX-75dBm for LTE | ||
| Standard Power Consumption | Average Operating Current:220mA@RX-75dBm for LTE | ||
| Standard Power Consumption | Max Current:800mA@RX-104dBm | ||
| Receiving Sensitivity | -106dBm | ||
| Battery | Polymer Lithium Battery | ||
| Charge Mode | TYPE-C/ Seat-charger | ||
| Antenna | External SMA, PCB Antenna | ||
| Operating Temperature | -20℃ ~ +50℃ | ||
| Weight | 310g | ||
| Size: Length*Width*Thickness(mm) | 125x60x36(Without Antenna) | ||
| SIM Card | Nano SIM | ||
| GPS (Optional) | |||
| Frequency | 1575.42MHz | Tracking Sensitivity | -155dBm |
| Capture Sensitivity | -143dBm | First Positioning Time(Outdoors) | Hot Start:4s |
| Capture Sensitivity | -143dBm | First Positioning Time(Outdoors) | Cold Boot:55s |
| Refresh Rate | 2-4HZ | Antenna | Active Antenna |
| Power Consumption | 35mA | Check | Native Latitude And Longitude Display And Platform Scheduling Software |
| IP66 waterproofed | |||
| Polymer Lithium Battery | |||
| GPS | |||
| Multi-group Listening | |||
| Multi-member Single Call | |||
| Native Platform Upgrade | |||
| Intercom Prompt Sound Switch | |||
| Key Lock | |||
| Battery Level Display/Low Battery Alert | |||
| Platform System:REALPTT | |||
| Support K-headsets | |||
| K-head Write Code And Frequency Line | |||
| SK1/SK2 Customization |
1 × Portable radio
1 × Antenna
1 × Li-ion battery pack
1 × Desktop Charger
1 ×Belt clip
1 ×The sling
Custom logo printing, private labeling, customized packaging, firmware development and OEM/ODM communication solutions are available for distributors and system integrators worldwide.
Custom product development with your branding, specifications, and packaging requirements.
Advanced digital encryption, noise cancellation, and energy-efficient radio technology.
Dedicated after-sales support with technical consultation and warranty service worldwide.
